Bush Hog BRC115
BRC Flail Crop Shredders BRC115
Overview:
Cutting Width: 180-inches to 300-inches
Number of Blades: 168- 272
Cutting Height: 1-inch to 18-inches
Features
Performance Features
- Blades chop through tough cotton, BT corn stalks, milo, rice, wheat, or vegetable stubble
- Re-cutter bar speeds up decomposition of plant residue to get nutrients back into the ground quickly
- Frame provides ground cover to minimize wind and water erosion
- Available in 15, 18, 20, and 25-feet widths to fit your crop’s row spacing
Specifications
| Models | BRC115 |
| Cutting Width | 180-inches |
| Overall Width | 204-inches |
| Cutting Height | 1-inches to 18-inches |
| Hitch Types | CAT II-III QH Lift, Semi-Mount, or Pull Type |
| Cutter Shaft Diameter | 10-3/4-inches |
| Min PTO HP Required | |
| Lift | 120 HP |
| Semi-Mount | 100 HP |
| Pull-Type | 100 HP |
| Gearbox Rating** | 207 HP |
| PTO Type | 1,000 RPM |
| Blades | Hard Surfaced: No "D" Rings |
| Blade Tip Speed (FPM) | 12,620 |
| No. of Blades | 168 |
| Driveline Size | Cat. 5 or 6 |
| Driveline Protection | 5 x 5V Banded Belt |
| Rotor Bearing Protection | Anti-Wrap Seal Protector |
| Cutter Shaft Bearings | 2 9/16-inches Double Row Spherical Roller, Triple Sealed |
| Hood Thickness | 3/16-inch with 3/16-inch Internal Wear Liner |
| End Plate Thickness | 1/4-inch |
| No. of Axles | 4 |
| Wheel Hub Size | 5-Bolt |
| Tire Size/Type | 6.70-5 Ribbed |
| Safety Deflector Type | Standard |
| Weight (Approx.) | 4,600-lbs. |
