| Horsepower Rating |
70 to 125 |
| Transports Width |
145” |
| Working Width |
144 3/16” |
| Capacity |
2 3/4 cu. yds. |
| Weight with Weight Box without material in weight box: |
|
| Tilt Axle: |
1700 (lbs.) |
| No Tilt Axle: |
1580 (lbs.) |
| Weight of Material in Weight Box |
760 |
| Depth of Box |
39” |
| Maximum Cutting Depth |
5” below grade |
| Dump Clearance |
21” |
| Maximum Tilt Depth To the Right |
8 1/4" |
| Maximum Tilt Angle |
3 1/2” |
| Tongue/Cross Tube Construction |
4” x 4” x 1/4” tubing |
| Side Plate Construction |
3/8” x 24 5/16” high x 39 3/4” deep |
| Moldboard Construction |
1/4” x 24 1/4” high when formed |
| Cutting Edge |
1/2” x 6” reversible & replaceable |
| Cutting Edge Reinforcement |
3” x 3” x 5/16” angle plus a 1/4” mold board = 9/16” at the cutting edge |
| Tires |
New 9.5L x 15 8-PLY RIB TL on 5-Bolt Rim with 5.5” bolt center |
| Maximum Transport Speed |
20 MPH |
| Lift Cylinder |
3 1/2” x 8” ASAE |
| Tilt Cylinder |
3 1/2” x 8” ASAE |
