Hustler 42" Kawasaki FR651
Raptor 42" Kawasaki FR651
Overview:
- 42” welded-steel deck
- Heavy-duty fabricated frame and deck – unmatched durability
- Exclusive SmoothTrak™ steering – responsive, precise control
- Patented automatic parking brake
- Powerful engine options
- Engine guard standard
Features
ENGINE GUARD
Provides protection to the engine and adds to great look of machine.
WELDED STEEL DECK
Heavy-duty design for unmatched durability. Up to 52" deck size available.
FABRICATED STEEL FRAME
Hustler's heavy-duty fabricated frames are built tough.
SMOOTHTRAK™ STEERING
Responsive, precise steering control.
AUTOMATIC PARK BRAKE
Auto engages when steering levers are open.
POWERFUL ENGINE OPTIONS
Kawasaki and Kohler engine options available.
Specifications
| Engine | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| MANUFACTURER | Kawasaki |
| HP (PER SAE J 1995.) | 21.5HP |
| DISPLACEMENT | 726cc |
| COOLING | Air Cooled |
| AIR CLEANER | Single Stage |
| ENGINE WARRANTY | 3 year |
| DRIVE SYSTEM | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| TYPE | Dual Hydrostatic |
| PUMPS | n/a |
| WHEEL MOTORS | n/a |
| HYDRAULIC LINES | n/a |
| HYDRAULIC COOLING | n/a |
| RESERVOIR CAPACITY | n/a |
| TRANSMISSION | HydroGear EZT |
| SPEED | 6.5 mph |
| PARKING BRAKES | Patented Automatic |
| DECKS | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| CUTTING WIDTH | 42" |
| CUTTING HEIGHTS | 1.5"-4.5" |
| DECK LIFT | Hand Operated |
| DEPTH | 4.1" |
| BLADES | 2 |
| BLADE LENGTH | 2 - 20.50" x 2.25" x .188" |
| BLADE TIP SPEED | 16,700 fpm |
| SPINDLES | Aluminum w/ 3/4 Shafts and Triple Protection Sealed Ball Bearings |
| DECK BELTS | n/a |
| DRIVE | Electric PTO Clutch |
| CONSTRUCTION | 11ga. Fabricated |
| SPINDLE MOUNTS | Reinforced 14ga. |
| IMPACT/TRIM AREAS | 1/4" x 3/4" Steel Bar |
| CONSTRUCTION | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| FRAME | 3.25" x 1.5" x .120" Steel |
| DECK CARRIER FRAME | n/a |
| ENGINE/TRANSMISSION FRAME | n/a |
| ENGINE PLATE | n/a |
| FRONT AXLE | Fabricated w/ Sealed Ball Bearings |
| FRONT CASTER WHEELS | Commercial Duty Steel Roller Bearings, Greasable |
| FRONT CASTER FORKS | Fabricated 1/4" Steel |
| OPERATOR PLATFORM | n/a |
| GENERAL | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| SEAT | Molded Vinyl, Adjustable, Suspension Springs |
| FUEL CAPACITY | 3 gal. |
| CUP HOLDER | Yes |
| FRONT TIRE | 11 x 4 |
| DRIVE TIRE | 18 x 8.50 - 8 |
| PRODUCTIVITY | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| ACRES PER HOUR | 2.2 |
| DIMENSIONS | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| WEIGHT | 479 lbs. |
| HEIGHT | 39" |
| HEIGHT W/ ROPS UP | n/a |
| HEIGHT W/ ROPS FOLDED | n/a |
| LENGTH | 73" |
| WIDTH | n/a |
| WIDTH W/ CHUTE UP | 44.42" |
| TIRE WIDTH | 41" |
| DIMENSIONS W/ CATCHER | |
| ZERO-TURN CONFIGURATION | 42" Kawasaki FR651 |
| CATCHER TYPE | 2-bag |
| POWERED/NON-POWERED | Non-powered |
| CATCHER CAPACITY | 5.4 bushel |
| MOWER LENGTH W/ CATCHER | 96.4" |
| MOWER WIDTH W/ CATCHER | 54.9" |
