Land Pride CA1556

Double tap to zoom

FEATURES	BENEFITS
Formed 10 Ga. mainframe and rotary supports	Formed 10 Ga. plates offers good strength and appearance.
Expanded metal in weight tray	Adds safety over spoon area, doesn’t allow foreign weight object to fall into spoon area, keeps cores from being thrown forward.
16 Ga. x 1/2” I.D. harden spring steel spoons with beveled edge	Penetrates the ground easier than spoons constructed of a heavier gauge material and/or larger diameter bodies.
Individual Spoon Replacement	Requires removal of only two bolts to replace a worn-out spoon. Don’t have to disassemble the whole rotary section to get to the spoons.
4 1/2” Gang spacing	Offers optimum core pulling pattern.
Spoon gangs	Spoon gangs are independent of each other allowing for less side load torque on each gang and tearing of the turf during turns.
Spoon gang greasing	Each gang has a grease zerk for smooth rotation.
3 - Storage stands	Keeps the spoons off the ground while in storage and aids in hooking-up to the tractor.
6 3/16’ Spoon spacing – forward travel	Offers optimum aeration.
48” = 4.5 Aeration cores per sq. ft.; 56” = 4.7 Aeration cores per Sq. ft.; 64” = 4.8 Aeration cores per Sq. ft.; 72” = 5.0 Aeration cores per Sq. ft.	Provides good aeration per square foot.
Weight tray	Additional weight can be easily added to the aerator.

Model No.	CA1556
Working Width	50"
Overall Width	56 5/16"
Overall Length	24 7/8"
Overall Height (With support stands up)	31 13/16"
Weight	170 lbs.
Max. allowable added weight in Weight Tray	400 lbs.
Number Of Spoons	66
Spoon Material	16Ga. hardened spring steel, Replaceable.
Spoon Spacing in forward travel	6"
Spoon Penetration	3" Depending on ground conditions and added weights.
Plug Size	1/2" Diameter
Gang spacing	4 1/2"
Number of Gangs	11
Frame Construction	Channel Formed 10 GA sheet
Hitch	Cat. 0, Cat. 1 & Cat. 1 limited
Quick Hitch	Fits Land Pride’s Quick Hitch Models QH05 and QH15
Number of Support Stands	3
