Land Pride GB25108

Double tap to zoom



Features

Bucket
Features Benefits
3/16" Grade 50 high strength steel shell Improved strength & wear versus mild steel
Five 1/2" x 5" bottom wear plates Extends bucket life
Reinforced bucket corners & side edges Adds strength & extends bucket life
5/8" x 6" drilled cutting edge Accepts optional bolt on cutting edge
Optional 5/8" x 6" bolt on cutting edge Reversible and replaceable; extends life of cutting edge
Upper torque tube/lower torque channel Prevents twisting
90", 96" & 108" widths available Fits wide range of tractors
1.0-1.2 Cu. Yd. struck capacity Allows high volume material handling
Quick release grapple mounts Allows grapple to be installed/removed quickly
Grapple
Features Benefits
High strength cast grapple tines Stronger and better looking than welded tines
Tubular steel construction Resists twisting
Parking stands Allows grapple to be stored upright when not in use
Spill guard Helps contain loose material
Dual 3" 3500psi cylinders Large cylinders handle high pressure & loads
Hose kit included Hoses provided to center tees or valve
Optional lock valve Prevents hydraulic bleed-off / improves cylinder control
Quick release grapple Four pin mount system
Large 84" opening Handles large bales and high volumes of material
Greasable pivot points Extends grapple life

Specifications

Model GB25108
Hitch Style Universal
Quick-Attach
Weight (Optional BOE and
Valve included)
1792 lbs.
Bucket Capacity (Struck) 1.18 cu yd
Overall Width 108"
Grapple Opening (With BOE) 84"
Number of Tines 5
Tine Construction Bolt-on ductile iron tine with reinforced gussets
Tine Thickness 3/4"
Hydraulic Cylinder Dual 3" x 14" x 1 1/2" rod
Maximum Pressure Rating 3500 psi
