Land Pride LM25108
LM25 Series Light Material Bucket LM25108
Overview:
Great for moving large volumes of loose material, snow removal, cleaning bedding and manure from events.
Features
| Attaches to power equipment easily | Uses Skid Steer Universal Quick Hitch design for quick and easy attachment. |
| Designed to fit skid steer loaders and tractor loaders equipped with the Universal Quick Hitch design. | The univers |
| Reinforced bucket back and sides | Adds strength and extends bucket life |
| Torque tube along the back | Strengthens bucket and distributes loads evenly to the hitch. |
| High back design with cutouts | Increases bucket capacity and the cutouts provide increased visibility |
| Weld-on 3/4" x 6" cutting edge with bolts holes. | Strengthens leading edge of bucket. Bolt holes accept optional bolt-on cutting edge. |
| 5/8" x 8" Optional bolt-on cutting edge | Bolt-on cutting edge is reversible to extend the life of the blade and replaceable to extend the life of the bucket and its weld-on cutting edge. |
| 84", 96", and 108" Widths available | Fits wide range of skid steers and tractors loaders with a universal quick hitch. |
| Struck capacity: 30.9, 35.4, & 40.4 cu. ft. | Allows high volume material handling. |
Specifications
| Model Number | LM25108 |
| Weight (without optional cutting edge) | 869 lbs |
| Struck capacity | 40.4 cu ft |
| Overall width | 109" |
| Overall height | 33 1/4" |
| Hitch type | Skid steer type Universal Quick-Attach, meets ISO 24410 |
| Bucket floor thickness | 3/16" |
| Bucket side wall thickness | 1/4" |
| Bucket cutting edge thickness | 3/4" |
| Working depth of bucket | 41 1/4" |
| Optional bolt-on cutting edge | Reversible and replaceable |
