Snow Plows Super-V2 SS 9' 6"

Double tap to zoom



Features

Performance

Versatility At The Touch Of A Button

When you want the convenience of a "V" blade, scoop blade or straight blade, you want a Meyer Super-V plow. Our exclusive one-button controller lets you put the plow in just about any configuration. The dual-acting cylinders lock the blade so you can back drag snow in any blade position.

Reliability

In the snowplowing business, downtime is not an option. That’s why the Super-V LD is built using Reliable Over-time Construction (ROC)… the detailed things we do to make our plows more rugged and reliable. ROC is the result of manufacturing improvements and state-of-the-art technology combined with stringent quality control procedures.

Ease of Use

EZ On, EZ Off In Seconds

When it’s cold, wet and dark, struggling with a stubborn snow plow is the last thing you want to do. That’s why Super-V LD has our EZ-Mount Plus mounting system conveniently attaches or detaches in well under a minute and leaves the vehicle with an off-the-assembly-line appearance when not attached. Unlike competitors that have up to three plugs, the EZ-Mount Plus system comes with just one patented plug to connect/disconnect. And Meyer’s free-standing jack stand allows you to adjust the plow’s height on uneven or shifting surfaces for easy on/off.

Fleet Management

EZ-Mount Plus mounting systems are fleet-friendly because the Super-V LD and Lot Pro LD moldboards and controllers are interchangeable. Super-V LD moldboards can also be attached to our time-tested EZ-Mount Classic® mounting systems.

Specifications

  • Type: Bottom-Trip
  • Vehicle: 1/2-ton trucks
  • Construction: Steel



Blade Model #: Super-V2 SS 9' 6" Blade Type: Bottom-Trip Moldboard Length:9' 6" 290 cm Moldboard Height:29.5"-38.25" N/A
Moldboard Gauge:12 ga 2,7 mm Vertical Ribs: 4 per wing Plow Trip Springs: 2 per wing Cutting Edge:1/2" x 6" 1,27 cm X 15,24 cm
Avg Width at Full Angle:99" 251 cm Angling Rams:1-1/2" x 12" double acting 3,81 cm x 30,48 cm Weight Complete:1124 lbs 510 kg
