Spreaders SP-9800X
Super Maxx™ II SP-9800X
Overview:
Super Maxx™ II
Offering huge capacities up to 6 cubic yards, Super Maxx™ II Series spreaders keep you out on the road for longer application intervals on the largest jobs. Super Maxx II models are equipped with a wide variety of original features that contribute to a simplified user experience, from setup and mainte... + Read More
Features
Wet/Dry Delivery
Within a unique wet/dry chamber, the auger feed system mixes brine with the spreading material before delivering it to the spinner.
Cab Forward Design
The cab forward hopper delivers better payload distribution to reduce stress on the truck.
Stowable Spinner Housing
When not in use, the low-profile spinner assembly can be flipped into the upright position for easy storage, providing full hitch access for towing.
Adjustable Spinner
The 12-inch stainless steel spinner contains adjustable cups and a deflector for maximum control over spread pattern.
Digital Speed Control
The integrated pendant-style control has a digital readout and dials for independently adjusting the variable-speed spinner and auger.
Heavy-Duty Auger Transmission
Each spreader’s heavy-duty auger transmission powers material through the spreader easily and efficiently.
Pre-Wet Integration
Users can choose to have the spreaders equipped with an optional pre-wet liquid tank system.
Frame Coating
Durable steel frame includes enhanced corrosion control finish with 6-part organic top coat process.
Fitted Tarp
A tarp fitted to the spreader’s dimensions protects material from outside weather elements.
Top Screen
A top screen effectively retains material while allowing visibility into the hopper.
Vibrator
Attached vibrator reduces material clumping for continuous material flow.
Inverted “V”
Patented vibrating baffle configuration maximizes material flow.
Lighting
FMVSS 108 rated brake light and LED safety strobe work light offer better equipment visibility in dark or snowy conditions.
Specifications
| Model | SP-9800X |
| Dimensions | |
| Empty Weight | 1,100 lb |
| Overall Length | 155" |
| Overall Height | 55" |
| Overall Width | 66" |
| Floor Length | 122" |
| Floor Width | 66" |
| Hopper Length | 120" |
| Hopper Width | 66" |
| Operational | |
| Capacity (Volume) | Struck 6.0 cu yd |
| Capacity (Volume) | Rounded 6.5 cu yd |
| Capacity (Weight) | 15,000 lb |
| Spreading Width | Up to 40' |
| Electrical | |
| Speed Control | Digital, self-diagnosing dual variable-speed control with auto reverse |
| Wiring Harness | Multiple gauge wiring harness with weather-tight plugs and connectors |
| Construction | |
| Frame | Heavy-duty steel with enhanced corrosion control finish with unique 6-part organic top coat process |
| Hopper | One-piece LLDPE safety yellow poly with integral vertical rib construction |
| Motors | Dual, 12-volt DC motor mounted in weather resistant enclosure |
| Spinner Drive Assembly | Compact, independent weather-resistant (spinner assembly is stowable for transport |
| Spinner | 12" heavy-duty stainless steel adjustable cupped fin spinner (for varying spread pattern) |
| Auger Drive Assembly | Heavy-duty solid steel construction with maximum-torque motor transmission drive |
| Auger | 7" heavy-duty variable pitch steel flighting |
| Mounting | Truck bed mounted with tie-down straps and controls |
| Standard Equipment | |
| Top Screen | Heavy-duty steel with angle iron edging |
| Cover | Fitted tarp |
| Vibrator | Standard heavy-duty 12-volt DC |
| Inverted | Patented vibrating inverted "V" to maximize material flow |
| Brake Light | Yes |
| Work Light | Yes |
