Woods TC/TCR60
Rotary Tillers TC/TCR60
Overview:
Woods’ line of rotary tillers couples the best design features with outstanding performance for the discerning user. Our 30- and 40-series received the ASABE award for outstanding Innovation in Product or Systems Technology 2017.
• 30- and 40-series models available as either forward or reverse rotation
• On initia... + Read More
Features
- 60-inch tilling width
- Tractor HP range: 20-45 hp
- Three-point hitch: Cat 1
- Available as either forward or reverse rotation
- Standard slip clutch driveline protection
- Sturdy rear tailgate evenly distributes dirt, leaving a smooth, flat seed bed
- Strong, cast-iron gearbox withstands rugged use
- Specifically designed for compact tractors
Specifications
| Tractor hitch | Cat 1 |
| Tractor Engine HP | 20 - 45 hp |
| Working width | 60" |
| Max. tilling depth | 7.5" |
| Weight | 597 / 604 lbs |
| Drive type | #80 chain |
| Num. Tines/ Num. Flanges | 42 / 7 |
| Tines per flange | 6 c-type |
| Rotar shaft rpm | 240 rpm |
| PTO driveline protection | slip clutch or shear bolt |
| Tractor PTO speed - rpm | 540 rpm |
| Gearbox housing | heavy-duty cast iron |
| Gearbox drain plug | yes |
| Convertible side shift (right) | 15.5" |
| Quick hitch compatible | yes |
