Woods CP12LFA
Cold Planers CP12LFA
Overview:
Top pivot design self-levels drum and chassis creating higher down forces and smoother cuts.
Optional Drums
Step drums and stripe removal drums are available for added versatility in special applications.
Features
- 12-inch cutting width
- Cutting depth range: 0-5 inches
- Manual controls attach to any skid steer
- Top pivot design to self-level drum and chassis for higher down force and smoother cuts
- Optional water kit for increased longevity
- Optional step drum and stripe removal drum for added versatility
Specifications
| Hydraulic flow classification | low-flow |
| Working width | 12" (304.8 mm) |
| Depth of cut | 0-5" (0-127mm) |
| Number of teeth | 36 |
| Side shift (right) | 0-22" (0-558.8 mm) |
| Tilt | +/- 19° |
| Hydraulic flow requirement | 13 - 23 gpm (49 - 87 lpm) |
| Hydraulic pressure requirement | 1,500 - 3,000 psi (103-207 bar) |
| Operating weight | 1,300 lbs (591 kg) |
| Depth control mechanism | mechanical |
| Tilt control mechanism | mechanical |
| Side shift mechanism | - |
| Hydraulic function activation means | manual |
