Woods CP16
Cold Planers CP16
Overview:
Top pivot design self-levels drum and chassis creating higher down forces and smoother cuts.
Optional Drums
Step drums and stripe removal drums are available for added versatility in special applications.
Features
- 16-inch cutting width
- Cutting depth range: 0-6 inches
- Manual controls attach to any skid steer
- Top pivot design to self-level drum and chassis for higher down force and smoother cuts
- Optional water kit for increased longevity
- Optional step drum and stripe removal drum for added versatility
Specifications
| Hydraulic flow classification | high-flow |
| Working width | 16" (406.4 mm) |
| Depth of cut | 0-6" (0-152.4 mm) |
| Number of teeth | 44 |
| Side shift (right) | 0-22" (0-558.8 mm) |
| Tilt | +/- 15° |
| Hydraulic flow requirement | 22 - 32 gpm (83 - 121 lpm) |
| Hydraulic pressure requirement | 2,000 - 3,500 psi 138-241 bar) |
| Operating weight | 1,750 lbs (795 kg) |
| Depth control mechanism | mechanical |
| Tilt control mechanism | hydraulic |
| Side shift mechanism | hydraulic |
| Hydraulic function activation means | manual or electric |
