Woods SG20B
Stump Grinders SG20B
Overview:
Mulch in minutes with Woods Alitec™ Stump Grinders`
Features
- Grinds stumps 28-inches above and 16-inches below ground
- Hydraulic requirements: flow 12-25 gpm, pressure 2,000-3,000 psi
- Telescoping head for less repositioning
- 24 Sandvik teeth on a 19.5-inch cutting wheel
- Choose manual or electro-hydraulic controls to easily manage swing, depth and extension
Specifications
| Overall length | 64.1" (1,628.1 mm) |
| Telescopic extension | 14" (355.6 mm) |
| Output torque | 130 - 195 lbs-ft (18-27 kg-m) |
| Cutting height above ground | 28" (711.2 mm) |
| Cutting height below ground | 16" (406.4 mm) |
| Cutting wheel width | 3.52" (89.4 mm) |
| Working width | 19.5" (495.3 mm) |
| Cutting wheel speed | 565 - 1,180 rpm |
| Swing range | +/- 45° |
| Max. stump diameter capacity | 32" (813 mm) |
| (without re-positioning) | |
| Type of teeth | Sandvik |
| Number of teeth | 24 |
| Operating weight | 800 lbs (364 kg) |
| Driveline | vane motor with internal relief |
| Hydraulic flow requirement | 12 - 25 gpm (45-95 lpm) |
| Hydraulic pressure requirement | 2,000 - 3,000 psi (138-207 bar) |
