Woods HC54

Double tap to zoom



Features

  • 54-inch Low-Horsepower Single-Spindle Cutter
  • Three-point hitch: Cat 1
  • Tractor HP range: 15-45 hp
  • Cutting capacity up to 1-inch
  • Standard rear metal band deflectors and rubber front belt shields
  • Optional chain shielding
  • Standard full-length skid shoes to glide easily over rough terrain

Specifications

PTO Horsepower 15-45 hp
Hitch category / type Cat 1 / cantilevered pin
Cutting width 54"
Transport width 58"
Maximum overall length 96.8"
Deck length 62.4"
Cutting height 1-9"
Cutting capacity 1"
Gearbox horsepower 65 hp
Gearbox output shaft diameter 1.57"
Blade tip speed 14,657
Blade rotation CCW
Deck side depth 9.4"
Approximate weight 487 lbs
Blade dimensions (2) .38" x 3"
Blade carrier oval stump jumper
Blade mount system blade bolt
Blade pin diameter 1.5"
Cutting deck thickness 11 gauge
Side frame thickness 11 gauge
Tail wheel - laminated tire 4" x 16"
Safety-shielded driveline Cat 3
Driveline protection slip-clutch or shear-pin
Tractor PTO speed 540 rpm
Quick-hitch compatible yes
Belting / Banding chain shielding optional
